Cut to length - sold by the foot. Enter the desired footage in the QTY box.
Minimum 1' to maximum 750'. Please call for longer put ups.
Color:
Black
Applications:
Type conductors are primarily used in control cabinets, in machine tool applications and appliance wiring applications. Applications requiring Type MTW conductor is appropriate for use in dry locations at 90°C, or not to exceed 60°C in wet locations or where exposed to oils or coolants. Applications requiring Type AWM conductor is appropriate for use at temperatures to not exceed 105°C in dry locations.
Bare Copper Stranding:
E314968 350 MCM (UL) MTW OR THHW FOR CT USE OR AWM 1339/1284 600V OR 1032/10269 1000V VW-1 SUN RES---240954 CSA AWM I A/B 105C 600/1000V FT1
Specifications*:
Size: 350 MCM
Number of Strands: 3458
Temp: 105°C
Insulation Thickness: 0.100 inches
Outside Diameter: 0.950 inches
*Data provided on this page is subject to change based on different manufacturers variances.
