Applications
Enterprise Networks, Data Center
Features
- Compatible with Plug&Play Systems modules
- Designed to support Plug&Play Systems applications Splice in the housing
- Saves rack space and the cost of the second housing Removable top (1U, 2U)
- Maximizes ease of access Transparent front door (04U and 02U)Permits viewing while protecting installed patch cords Large removable fiber guides in front
- Effectively manage high patch cord densities
Specification Description
Mounting Type: Rack 19-in, Rack 23-in
Product Type (FOH): Rack-Mountable Hardware
Fiber Capacity: Up to 48 fibers installing FC/SC/ST Compatible connectors, or up to 96 installing LC connectors
Height Unit: 1U
Housing Color: Gray
Housing Type: PCH
Locking Availability: Front or rear
Maximum Number of Panels per Housing: 4
Panel or Module Type: CCH
Splice Tray Options: 6 category, 2R, 2S, 2S-Long, 3 category 4R, 4S, 4S-Wide
Dimensions (HxWxD) (Metric-cm): 9x43x42 cm
Dimensions (HxWxD) (US): 3.5x17x16.5 in
Tech Info
Free of hazardous substances according to RoHS 2002/95/EG
Technical
Connectorized Fibers
24/96
Loaded
UNLOADED
Type
RACK MOUNT
