Model:
PDPK006FB3010/F5, 370-BKTOM4-TBA-06
SKU:
PDPK006FB3010/F5, 370-BKTOM4-TBA-06
Availability:
In Stock
documents:
Spec Sheet
Request Quote
  0 reviews

Features

  • ARMOR-TEK Interlocking Armor is wound around the cable core
  • Each cable incorporates tight buffered optical fibers with DryGel water blocking system in the core cable
  • Cables feature fungus-resistant jacketing, and are sunlight resistant per UL 444 clause 7.22
  • An upjacketed aramid strength member is centrally located within the 24 fiber cable design. A glass reinforced (GRP) antibuckling member is used as a central strength member for fiber counts from 36 to 144 that feature 12 fiber subunits
  • Aluminum interlock armor is covered by a plenum rated jacket
  • Flexible cost-saving design, easy to install and terminate, direct termination is enabled
  • Tight buffered (900 Um) 6 to 144 count fiber construction plenum rated indoor/outdoor designs is ideal for backbone installations
  • Single-mode, multimode, and hybrid designs available
  • Also available in a riser-rated Low Smoke Zero Halogen design
  • OFCP Rated

Technical

Armored
YES
Cable Type
TIGHT BUFFERED
Fiber Type
OM4 LAZER-OPTIMIZED 50 MICRON, 10 GIG TO 550 METER
Fire Rating
PLENUM
