Spec Sheet
Specification Description
Industry Standards.RoHS/ELV Compliance: RoHS compliant, ELV compliant
Industry Standards.Lead Free Solder Processes: Not relevant for lead free process
Body Features.Number of Positions: 64
Packaging Features.Packaging Method: Tray
Mechanical Attachment.Panel Mount Retention: Without
Product Type Features.Product Type: Connector
Product Type Features.Insulation Diameter (mm [in]): 1.14 [.045] Max.
Electrical Characteristics.Shielded: No
Product Type Features.Product Category: Connectors
Product Type Features.Wire/Cable Type: 7 Strand, Solid
Product Type Features.Gender: Plug
Product Type Features.Profile: Standard
Body Features.Wire Range (Solid) (mm [AWG]): 0.51-0.40 [24-26]
Product Type Features.Connector Classification: IDC
Mechanical Attachment.Flange Thickness: Thick
Product Type Features.Connector Design: PS
Housing Features.Housing Color Dot Designation: Blue
Body Features.Wire Range (Stranded) (mm [AWG]): 0.20 [24]
Product Type Features.Mating Connector Lock Type: Screwlocks
Product Type Features.Slot Type Letter Code: B
Product Type Features.Mating Connector Lock: With
Contact Features.Contact Plating, Mating Area, Material: Gold (30), Gold Flash over Palladium Nickel
