Features
- For 5/8 Inch Latch or 3/4 Inch Latch with 1/8 Inch Door Gap
- Latch Position Status Standard Keeper Closed and Deadlocked/Unlocked Status Standard
- Field Selectable Failsecure - Failsafe
- Field Selectable Voltage, 12/24 Volt AC/DC 1/4 Inch Horizontal Aligment Adjustment
- Low Profile, 1-3/16 Inch Deep
- Plug-In Wire Connectors
- Mounting Tabs Non-Handed
- All Stainless Steel Parts with Durable Die-Cast Body for Corrosion Resistance Fewer Moving Parts for Maximum Life
- Stainless Steel Standard with Square Cor Faceplate
- Aluminum Standard with Radius Corner Faceplate
- Made in USA
Technical
Finish
US32D SATIN STAINLESS STEEL
Frame Material
ALUMINUM OR HOLLOW METAL
Locking State
SELECTABLE FS OR FSE
Max Latch Length - Inch
MAXIMUM 3/4 INCH THROW
Mounting
FOR CENTERLINE INSTALLATIONS
Product Type
FOR USE WITH CYLINDRICAL LOCK
Sales Category
ELECTRIC STRIKE
Switches
LATCHBOLT MONITOR
Voltage and Duty INT
SELECTABLE 12/24V AC/DC INT
