ABB A16-40-00-80 AC Nonreversing IEC Contactors 4-P N/O, 240 V AC Coil, 30A

Applications

For Controlling Non-Inductive Or Slightly Inductive Loads (I.E. Resistance Furnaces) And Generally For Controlling Power Circuits Up To 690V AC And 440 V DC; For Contactors Can Also Be For Many Other Applications Such Lighting. A Line contactors are ma inly used for controlling 3-phase motors and for controlling power circuits corresponding to their operating characteristics up to 690 and even 1000V AC. and 440 V DC.

Features

• Maximum UL/CSA horsepower ratings according to UL508 and CSA22.2 No. 14
• Includes NEMA sizes 00 - 3
• CE mark
• Compact space saving design
• Standard auxiliary contact configurations: A9 - A40 1 NO or 1 NC and A50 - A110 1 NO & 1 NC
• Contactor sizes A50 - 0 can be supplied without auxiliaries
• Additional auxiliary contact blocks are available
• D.C. ratings & D.C. control operation available
• Fast, snap-on DIN rail mounting
• Double break contact design
• Snap-on front mounted accessories include mechanical ch, pneumatic timer, and 1 & 4 pole auxiliary contact blocks
• Contactors ensure positive safety between their auxiliary contact blocks.
• Easy coil change
• Captive terminal screws
• NEMA, UL, IEC, CSA, VDE and most other international standards
• Touch safesign: All connection terminals are protected against accidental touch
• Terminals supplied open for ease of wiring
• Operates over an extended voltage range of 85% to 110% of rated control voltage
• Screwdriver guide holes

Specification Description

Coil Voltage: 220 - 230 V AC At 50 Hz, 230 - 240 V AC At 60 Hz
Contact Configuration: 4 NO (Main)
Wattage: 4 kW At 220/230/240 V, 7.5 kW At 380/400 V, 9 kW At 415/440/500/690 V
Connection: Screw Terminal
Size: 44 mm Width X 74 mm Height X 74 mm Depthperating Temperature: Fitted With Thermal Overload Relay: -25 To +55 deg C, Without Thermal Overload Relay: -40 To +70 deg C

Tech Info

UL Listed, CSA, CE, BV, CCC, DNV, GL, GOST, LR, RINA, RMRS Certified, RoHS Compliant
