ABB AF63-30-11-69 AF63 Contactor, 3 NO Power, 1 NO/1 NC Aux, 48-130 V AC/DC

Applications

ABB- Line - a system concept
Designed for easy and safe installation and maintenance
Easy to integrate with other system components,
Compact design.
A complete range of accessories
Complies with the latest international as well as national standards

Features

• AF contactors include an electronic coil interface providing reduced pull-in and holding consumption, particularly for AC control circuits
• Only four coils are needed to cover control voltages between 24...500 V 50/60 Hz or 20...500 V DC.
• AF offer extended operating limits and are suitable worldwide for different control voltages. e.g.: the coil 100...250 V 50/60 Hz - DC is suitable for Europe (230 V 50 Hz) and for North America (120 V 60 Hz and 208 V 60 Hz).
• AF contactors can manage large control voltage variations
• AF contactors equipped with a 24...60 V 50/60 Hz - 20...60 V DC coil allow direct control by 24 V DC 500 mA PLC-output
• AF contactors withstand short voltage dips and voltage sags (SEMI F47-0706 compliance)
• AF contactors have built-in surge protection and do not require additional surge suppressors.
