Applications
For Commercial And Industrial Purpose
Specification Description
Voltage Rating: 12 - 60 V DC
Amperage Rating: 1 A
Trip Type: Thermal Magnetic
Trip Range: Magnetic: 8 - 12 A, Thermal: 15 A
Interrupt Rating: 14 kA
Number Of Poles: 1
Enclosure: IP20, IP40 With Cover
Actuator: Insulation Group II, Black, Sealable,Marking
Material: Insulation Group I, RAL 7035
Length: 71 mm
Width: 17.5 mm
Height: 92 mm
Operating Temperature: -25 To +55 deg C
Environmental Conditions: Storage Temperature: -40 To 70 DEG C
Recommended Screw Driver: Pozidriv 2
Connecting Capaconductor: 18 - 4 AWG, Busbar: 18 - 8 AWG
Mounting: DIN Rail: TH35-15 (35 mm Length X 15 mm Width), TH35-7.5 (35 mm Length X 7.5 mm Width)
Tightening Torque: 25 in-lb
Insulation Voltage: Phase To Ground: 250 V AC, Phase To Phase: 500 V AC
Tripping Chacteristic: K
Energy Limiting Class: 3
Overvoltage Category: III
Dielectric Test Voltage: 2 kV At 50/60 Hz For 1 min
Endurance: Electrical: 6000 Cycles, Mechanical: 20000 Cycles
Impulse Withstand Voltage: 4 kV
Pollution Degree: 2
Contact Position Ition: ON/OFF
Tech Info
UL 489 Listed, CSA Certified
