Applications
For Commercial And Industrial Purpose
Specification Description
Voltage Rating: 12 - 60 V DC
Amperage Rating: 4 A
Trip Type: Thermal Magnetic
Trip Range: Magnetic: 32 - 48 A, Thermal: 4.2 A
Interrupt Rating: 14 kA
Number Of Poles: 1
Enclosure: IP20, IP40 With Cover
Actuator: Insulation Group II, Black, SealablO Marking
Material: Insulation Group I, RAL 7035
Length: 71 mm
Width: 17.5 mm
Height: 92 mm
Operating Temperature: -25 To +55 deg C
Environmental Conditions: Storage Temperature: -40 To 70 DEG C
Mounting: DIN Rail: TH35-15 (35 mm Length X 15 mm Wi TH35-7.5 (35 mm Length X 7.5 mm Width)
Recommended Screw Driver: Pozidriv 2
Tightening Torque: 25 in-lb
Connecting Capacity: Conductor: 18 - 4 AWG, Busbar: 18 - 8 AWG
Tripping Characteristic: K
Energy Limiting Class: 3
Insulation Voltage: Phase Tound: 250 V AC, Phase To Phase: 500 V AC
Endurance: Electrical: 6000 Cycles, Mechanical: 20000 Cycles
Contact Position Indication: ON/OFF
Impulse Withstand Voltage: 4 kV
Overvoltage Category: III
Pollution Degree: 2
Dielectric Test Voltage: 2 kV At 0 Hz For 1 min
Tech Info
UL 489 Listed, CSA Certified
