Spec Sheet
Features
- Smaller tube size reduces overall cable diameter and improves handling
- The All-Dry Construction improves cleanliness and preparation times
- Cable construction is small and light, improving pathway utilization and reducing installation forces
- Meets requirements for tight buffered constructions and suitable of installation in true OSP environmental conditions
Specification Description
Fiber Type: TeraSPEED, zero water peak single-mode fiber
Fiber Type Solution: TeraSPEED, zero water peak single-mode fiber
Fiber Type, quantity: 96
Fibers Per Subunit, quantity: 12
Jacket Color: Yellow
Total Fiber Quantity: 96
Buffer Tube/Subunit Diameter: 5.90 mm
Cable Weight: 361.0 lb/kft, 537.0 kg/km
Diameter Over Jacket: 23.10 mm
Subunit, quantity: 8
Environmental Space: Plenum
Installation Temperature: 0 C to +70 C (+32 F to +158 F)
Operating Temperature: -20 C to +70 C (-4 F to +158 F)
Storage Temperature: -40 C to +70 C (-40 F to +158 F)
Heat Age: -20 C to +85 C (-4 F to +185 F)
Low High Bend: -20 C to +70 C (-4 F to +158 F)
Temperature Cycle: -20 C to +70 C (-4 F to +158 F)
Flame Test Listing: NEC OFNP (ETL) and c(ETL)
Cable Type: Distribution
Construction Type: Non-armored
Fiber Short Description: P-096-DSMU
Subunit Type: Gel-free
Compression: 10 N/mm, 57 lb/in
Flex: 100 cycles
Impact: 4.34 ft lb, 5.88 N-m
Twist: 10 cycles
Minimum Bend Radius, loaded: 34.6 cm
Minimum Bend Radius, unloaded: 23.1 cm
Tensile Load, long term, maximum: 1,335 N, 300 lbf
Tensile Load, short term, maximum: 1,000 lbf, 4,450 N
Vertical Rise, maximum: 253.0 m
Cable Qualification Standards: ANSI/ICEA S-83-596-2001, Telcordia GR-409-CORE Issue 2
Tech Info
ISO 9001:2008: Designed, manufactured and/or distributed under this quality management system; RoHS 2002/95/EC: Compliant
