COMMSCOPE ENTERPRISE SOLUTIONS 760138768 P-036-DS-8W-FMUGR Plenum Distribution Cable, 36 fiber multi-unit wit

Features

• Small, compact module design offer improved density and is reverse compatible with the G2 modular cassette solution
• Translucent shutters and dust plugs allow for easy port identification utilizing a Visual Fault Locator (VFLs)
• Modules are availableith 12 or 24 LC connections or with 12 SC connections
• The Modular Panels offer excellent cable management and rear access, while minimizing bulk, complexity and potential restrictions to air flow
• The InstaPATCH 360 solution is iPatch-ready, offerinthe capability to upgrade to intelligent infrastructure management after the initial installation
• LazrSPEED modules and patch cords are constructed with LazrSPEED 550 OM4 fiber to provide headroom for future system upgrades
• TeraSPEED offers 60% incase in bandwidth due to Zero Water Peak in the E-band (1400 nm window) in single-mode applications
• Factory terminated and tested cable and apparatus for instant field connections with guaranteed quality and performance
• 24-fiber module option alignsell with systems that utilize a 8-fiber increment
• 12-fiber MPO connector based modular design enables simple connections
• Provides opportunities for lower total installed system cost (material plus labor)
• Up to 50% savings in space due to the inced density
• Designed for administrative convenience - guaranteed transmit-to-receive connectivity
• No special polarity components single module design, standard patch cords
• Easy upgrade path to parallel connectivity and wavelength division multiplg applications:
• - 40 Gbps / 100 Gbps Ethernet
• - 16 Gbps Fiber Channel
• Supports easy reconfiguration for moves, adds and changes
• Improved fiber patch cord management and improved labeling capabilitie

Specification Description

Fiber Type: TeraSPEED, zero water peak single-mode fiber
Fiber Type Solution: TeraSPEED, zero water peak single-mode fiber
Fiber Type, quantity: 36
Fibers Per Subunit, quantity: 12
Jacket Color: Green
Total Fiber Quantity: 36
Buffer Tube/Subunit Diameter: 5.90 mm
Cable Weight: 128.0 lb/kft, 191.0 kg/km
Diameter Over Jacket: 13.70 mm
Subunit, quantity: 3
Environmental Space: Plenum
Installation Temperature: 0 C to +70 C (+32 F to +158 F)
Operating Temperature: -20 C to +70 C (-4 F to +158 F)
Storage Temperature: -40 C to +70 C (-40 F to +158 F)
Heat Age: -20 C to +85 C (-4 F to +185 F)
Low High Bend: -20 C to +70 C (-4 F to +158 F)
Temperature Cycle: -20 C to +70 C (-4 F to +158 F)
Flame Test Listing: NEC OFNP (ETL) and c(ETL)
Cable Type: Distribution
Construction Type: Non-armored
Fiber Short Description: P-036-DSMU
Subunit Type: Gel-free
Compression: 10 N/mm, 57 lb/in
Flex: 100 cycles
Impact: 4.34 ft lb, 5.88 N-m
Twist: 10 cycles
Minimum Bend Radius, loaded: 20.6 cm
Minimum Bend Radius, unloaded: 13.7 cm
Tensile Load, long term, maximum: 1,068 N, 240 lbf
Tensile Load, short term, maximum: 3,560 N, 800 lbf
Vertical Rise, maximum: 500.0 m
Cable Qualification Standards: ANSI/ICEA S-83-596-2001, Telcordia GR-409-CORE Issue 2

Tech Info

ISO 9001:2008: Designed, manufactured and/or distributed under this quality management system; RoHS 2002/95/EC: Compliant
