COMMSCOPE SYSTIMAX SOLUTIONS 760159426 1091B RED C6A 4/23 U/UTP R3000 Copper Cable, Category 6A, 23 AWG, 4 Pair, Unshielded, UTP, Solid Bare Copper Conductor, PO/PVC, CMR, Riser Cable, Red Jacket, 3000Ft, Reels Only

Features

• Electrical performance guaranteed to meet or exceed the channel specifications of Amendment 1 to
• ISO/IEC 11801:2002 Class EA and ANSI/TIA-568-C.2 Category 6A up to 500 MHz when used as
• part of a GigaSPEED X10D UTP Channel in registered SYSTIMAX installations.
• ETL/cETL listed (except LSZH)
• Can support network line speeds up to at least 10 gigabits per second
• Qualifies for the SYSTIMAX 20-Year Extended Product Warranty and Applications Assurance when
• included as part of a registered SYSTIMAX GigaSPEED X10D channel

Specification Description

Category: 6A
Fire Rating: Non-plenum
Fire Rating 2: CMG, CMR
Brand: SYSTIMAXGigaSPEED X10D
Cable Component Type: Horizontal
Cable Type: U/UTP (unshielded)
Number of Pairs: 4
Jacket Color: Red
Condutor Material: Bare copper
Insulation Material: Polyolefin
Jacket Material: PVC
Cable Length: 3,000 ft
Voltage: 80 V
Condutor Guage: 23 AWG
Conductor Type: Solid
Number of Conductor: 8

Tech Info

ISO 9001:2008: Designed, manufactured and/or distributed under this quality management system; RoHS 2002/95/EC: Compliant
