CORNING 036ZUC-T4F22D20 ALTOS Lite Loose Tube, Gel-Free, Single-Jacket, Single-Armored Cables with FastAccess Technology36 F, SMF-28 Ultra fiber, Single-mode OS2

Applications

Aerial, Direct Buried, Duct

Features

• ALTOS Lite FastAccess Technology
• Corning’s ALTOS Lite FastAccess Technology refers to the combination of a Corning FastAccess Technology jacket with an innovative technology used to bind cable construction through the manufacturing process, eliminating the use of binder yarns and waterblocking tapes and up to a 60 percent improvement in cable access time. These technologies also reduce the overall risk of inadvertent fiber damage by reducing the need for sharp cable access tools. Stranded optical co re
• Elimination of overlapping yarn binders around stranded tubes to reduce end access time Fully waterblocked loose tube all-dielectric gel-free design
• Simple access and no clean up Single-armored construction
• Provides additional crush and rodent protction Polyethylene jacket
• Rugged, durable and easy to strip (while providing superior protection against UV radiation, fungus, abrasion and other environmental factors) Available with Corning’s SMF-28 Ultra fiber
• ITU-T G.652 D and ITU-T G.657 A1 compliant fiber ready for any application

Tech Info

Outdoor lashed aerial, duct and direct-buried, indoor when installed according to National Electrical Code (NEC) Article 770ANSI/ICEA S-87-640
