CORNING ECM-UM12-05-93T EDGE Module, 12 F, LC Duplex to MTP Connector, 50 um Multimode OM3

Applications

Data Center LAN/SAN

Features

• VFL-compatible shuttered LC adapters
• Creates one-hand operation and decreases time needed to test and troubleshoot a link
• Rear-loading capability
• Decreases the time to prepare and install modules into fiber housings
• High density
• Module enables fibers in a 4U housing and 144 fibers in a 1U
• Low insertion loss performance
• Improved performance specs allow for more mated pairs and/or longer link distances
• Corning CleanAdvantage technology and optimized dust cap
• Eliminates the need for scopg and cleaning prior to initial field connection

Specification Description

Fiber Category: 50 µm MM (OM3)
Product Type (FOH): Panels and Modules
Fiber Count (cable): 12
Polarity: Universal
Adapter Color Back: Aqua
Adapter Color Front: Aqua
Adapter Type Back: MTP
Adapter Type Front: Shuttered LC
Fiber Count: 12
Number of Adapters per Panel: 6
Connector Type (Conn A): MTP (pinned)
Ferrule Material (Conn A): Composite
Connector Type (Conn B): LC Uniboot
Ferrule Material (Conn B): Ceramic
Dimensions (HxWxD) (Metric-mm): 12x90x124 mm
Dimensions (HxWxD) (US): 0.463x3.53x4.87 in
Module Insertion Loss, Max: 0.5 dB
Wavelengths: 850 nm / 1.300 nm

Tech Info

Free of hazardous substances according to RoHS 2002/95/EG
