CORNING EDGE-CP48-90 EDGE Adapter Panel, MTP48 F, Bend-improved Single-mode OS2

Applications

Data Center, Data Center LAN/SAN

Features

• Provide MTP connection points between trunks and harnesses or extender trunks
• Can be installed or removed from the front or rear of a housing
• Facilitate simple upgrades to parallel optics
• Packaged in easy-open containers

Specification Description

Fiber Category: Bend-Improved SM (OS2)
Product Type (FOH): Panels and Modules
Connector Type A: MTP
Fiber Count: 48
Housing Color: Black
Housing Material: Composite
Number of Adapters per Panel: 4
Adapter Housing Color: Black
Adapter Housing Material: Composite
Adapter Style: Standard
Adapter Type: MTP
Dimensions (HxWxD) (Metric-mm): 9x100x125 mm

Tech Info

Free of hazardous substances according to RoHS 2002/95/EG
