Model:
4500C-12/24-630 10530601, CS318762SKU:
4500C-12/24-630 10530601, CS318762Availability:
In Stockdocuments:
Spec Sheet
Request Quote
Features
- Stainless Steel Construction
- Tamper Resistant
- Static Strength 3000 Pound
- Dynamic Strength 100 Foot-Pound
- Endurance 1,000,000 Cycles
- Field Selectable Fail Safe/Fail Secure
- Dual Voltage 12 or 24 Volt AC/DC
- Two Faceplates Provided to Accommodate a Va of Locksets
- Non-Handed
- Internally Mounted Solenoid
- Accommodates Upto a 3/4" Latchbolt
- Strike Body Depth 1-3/8"
- Plug-In Connector
- Trim Enhancer
- Full Keeper Shims for Horizontal Adjustment
Tech Info
UL 10C/1034/294, ANSI/BHMA A156.31, CAN4-S104, NFPA-252, ASTM-E152
Technical
ANSI Grade
GRADE 1
Finish
US32D SATIN STAINLESS STEEL
Frame Material
WOOD OR HOLLOW METAL
Locking State
SELECTABLE FS OR FSE
Max Latch Length - Inch
MAXIMUM 3/4 INCH THROW
Mounting
UNIVERSAL
Product Type
CYLINDRICAL OR MORTISE LOCKS
Pull Strength - Lbs
2001 - 3000 LBS.
Sales Category
ELECTRIC STRIKE
UL
UL 3-HOUR FIRE AND BURGLARY RESISTANCE
Voltage and Duty CONT
SELECTABLE 12/24V DC
Voltage and Duty INT
SELECTABLE 12/24V AC/DC INT
Warranty
5 YEAR LIMITED
