Model:
SB:1006-12/24D-630 10620401, CS263408SKU:
SB:1006-12/24D-630 10620401, CS263408Availability:
In Stockdocuments:
Spec Sheet
Request Quote
Features
- Stainless Steel Construction
- Tamper Resistant
- Static Strength 3070 Pound (Fail Secure)
- Dynamic Strength 350 Ft Pound (Fail Secure)
- Endurance 1,000,000 Cycles
- Fail Secure (Standard)
- Dual Voltage 12 or 24 Volt DC Continuous Duty
- Non-Handed
- Internalnted Solenoid
- Accommodates Upto 1" Deadbolt
- Plug-In Connector
- Full Keeper Shims for Horizontal Adjustment
- Trim Enhancer
Tech Info
UL 10C/1034/294, ANSI/BHMA A156.31, CAN4-S104, NFPA-252, ASTM-E152
Technical
ANSI Grade
GRADE 1
Finish
US32D SATIN STAINLESS STEEL
Frame Material
ALUMINUM, HOLLOW METAL, OR WOOD
Locking State
FAIL-SECURE (POWER TO UNLOCK)
Max Latch Length - Inch
MAXIMUM 3/4 INCH THROW
Product Type
COMPONENT
Pull Strength - Lbs
3000+ LBS.
Sales Category
ELECTRIC STRIKE
UL
UL 3-HOUR FIRE AND BURGLARY RESISTANCE
Voltage and Duty CONT
SELECTABLE 12/24V DC
Voltage and Duty INT
12 OR 24V DC
Warranty
5 YEAR LIMITED
