Spec SheetApplications
SC adapters provide a robust solution for LANs, public networks, storage area networks and fiber-to-the-desk applications. SC adapters can also be mounted in high-density applications within Opticom QuickNet Pre-Terminated MTP Cassettes and Fiber Enclo sures, and Opticom Fiber Adapter Panels (FAPs) and Enclosures.
Features
- TIA/EIA-604 FOCIS-3 compliant adapters
- Exceed TIA/EIA-568-B.3 requirements
- Compatible with Mini-Com(TM) products for complete modularity
- Improved protective cap fully surrounds split sleeve opening
- Choice of phosphor bronze or zirconia ceramic split sleeves to fit specific network requirements; zirconia ceramic split sleeves are required for single-mode applications
- Every adapter is laser marked with Q.C. number to assure 100% traceability
- Mini-Com(TM) SC Simplex Adapter Modules are commonly used with Mini-Com(TM) Patch Panels
- Mini-Com(TM) SC Duplex Adapter Modules are commonly used with Mini-Com(TM) Surface Mount Boxes
- SC simplex and duplex adapters are also available separately, and in patch panels or fiber adapter panels to provide a complete SC system solution
Specification Description
Fiber Optic Adapter Module
Color: Black
Sleeve Type: Split
Sleeve Material: Zirconia Ceramic
Includes: With (1) Aqua SC 10Gig(TM) OM3/OM4 Simplex Multimode Fiber Optic Adapter
Fiber Count: 1
Fiber Type: Simplex
Number Of Module Spaces: 1
Connector Type: SC (1 Type)
Dimension: 1.93 Inch Length x 0.62 Inch Width x 0.71 Inch Height (49 mm x 16 mm x 18 mm)
Tech Info
TIA/EIA-604 FOCIS-3 compliant adapters, Exceed TIA/EIA-568-B.3 requirements. RoHS Compliant, TIA/EIA-568-B.3 requirements
