Model:
PUR6A04WH-CG, CM-00423PND-6A-01-CSKU:
PUR6A04WH-CG, CM-00423PND-6A-01-CAvailability:
In Stockdocuments:
Spec Sheet
Request Quote
Features
- Compatible with Components of the TX6A-SD10GIGU/UTP Copper Cabling System with Matrix Technology (70 Meter Solution) for Increased Design Flexibility
- Provides Superior Suppression of Both PSANEXT and PSAACRF
- Improves the Installation Flexibility by Allowing Cable Combing in Existing Pathways Without Compromising Performance
- Provides the Highest Margins Above the Industry Standard for Both Electrical and Alien Crosstalk Performance
- Improves Fill Capacity, Cable Management, Reduces Required Bend Radius and Allows Efficient Use of Pathways and Spaces
- Separates Pairs for Exceptional Cable Performance
- Easy Identification of Remaining Cable to Reduce Installation Time and Cable Scrap
Technical
Category
CATEGORY 6A
Conductor Size
23 AWG (AMERICAN WIRE GAUGE)
Conductor Type
SOLID
Conductor/Pair Count
4 PAIR
Fire Rating
RISER
Jacket Color
WHITE
Shielded
U/UTP - UNSHIELDED TWISTED PAIR
Type
DATA
