PRYSMIAN GROUP 6131449 GenSPEED 5500 Premium Cat 5e Cable, Enhanced Transmission Throughput, CMP, U/UTP, White

Features

• Features: And Benefits
• Ensures increased headroom for future applications, lower bit-error rates, and higher signal transmission quality
• Enhanced signal-to-noise ratio, improving bit-error rate
• Performance guaranteed to 350 MHz
• TRU-Mark print legend contains footage markings from 1000’ to 0’
• Third-party verified for guaranteed performance
• Made in U.S.A.
• Applications:
• IEEE 802.3: 1000 BASE-T (Gigabit Ethernet), 100 BASE-TX, 10 BASE-T
• 155 Mp/s, 622 Mp/s ATM
• ANSI X3.263: 100 Mb/s
• IEEE 802.3af DTE Power (PoE)
• IEEE 802.3at DTE for PoE Plus
• Broadband and Baseband Analog Video

Specification Description

Conductors: 23 AWG CMR solid bare annealed copper; 24 AWG CMP solid bare annealed copper
Insulation: Non-Plenum: Polyolefin; Plenum: Fluoropolymer
Color Code: Pair 1: Blue-White/Blue; Pair 2: Orange-White/Orange; Pair 3: Green-White/Green; Pair 4: Brown-White/Brown
Rip Cord: Applied longitudinally under jacket
Jacket: Non-Plenum: Flame-Retardant PVC; Plenum: Low-Smoke, Flame-Retardant PVC

Tech Info

Standard Compliances
ANSI/TIA 568-C.2
ANSI/TIA 862 (Building Automation)
ISO/IEC 11801 Ed. 2.0 (Class D)
ICEA S-90-661 (Category 5e)
NEC/CEC Type CMR (UL 1666) for Non-Plenum
NEC/CEC Type CMP (NFPA 262) for Plenum
RoHS Compliant Directive 2002/95/EC
UL 44
