PRYSMIAN GROUP 7131790 GenSPEED 10,000 Cat 6A Cable, CMP, U/FTP, Red

Features

• Features: And Benefits
• Shielded design allowing for maximum pair separation, increasing key electrical performance parameters
• Individual pair shielding for EMI protection
• Typical positive PSACR beyond 500 MHz for increased available bandwidth
• TRU-Mark print legend contains footage markings from 1000’ to 0’
• Made in U.S.A.
• Applications:
• IEEE 802.3an: 10G BASE-T (10 Gigabit Ethernet)
• 1000 BASE-TX (Gigabit Ethernet)
• 2.4/1.2 Gb/s ATM
• IEEE 802.3af for PoE
• IEEE 802.3at for PoE Plus

Specification Description

Conductors: 23 AWG solid bare annealed copper
Insulation: Non-Plenum: Foamed HDPE; Plenum: Foamed Fluoropolymer
Color Code: Pair 1: Blue-White; Pair 2: Orange-White; Pair 3: Green-White; Pair 4: Brown-White
Shield: Each pair is individually shielded with an aluminum foil 24 AWG drain wire
Jacket: Non-Plenum: Flame-Retardant PVC; Plenum: Low-Smoke, Flame-Retardant PVC

Tech Info

Standard Compliances
ANSI/TIA 568-C.2
ISO/IEC 11801 Ed. 2.0 (Class E)
ICEA S-102-700 (Category 6)
NEC/CEC Type CMR (UL 1666) for Non-Plenum
NEC/CEC Type CMP (NFPA 262) for Plenum
RoHS Compliant Directive 2002/95/EC
UL 444
