Model:
7136100, CM-00423GEN-C6-02SKU:
7136100, CM-00423GEN-C6-02Availability:
In Stockdocuments:
Spec Sheet
Request Quote
Features
- Features: And Benefits
- Innovative cross-web design allowing for maximum pair separation, increasing key electrical performance parameters
- Gel-filled construction to prevent moisture migration in underground and wet applications
- Wide temperature range for extreme weather environments
- TRU-Mark print legend contains footage markings from 1000’ to 0’
- Made in U.S.A.
- Applications:
- Data transmission rates up to 2.4 Gb/s
- 1000 BASE-T (Gigabit Ethernet)
- 100/10 BASE-T (IEEE 802.3)
- 52/155 Mbps ATM
- Duct and conduit installations
- Not to be used aerially or direct buried
Specification Description
Conductors: 23 AWG solid bare annealed copper
Insulation: Polyolefin
Color Code: Pair 1: Blue-White/Blue; Pair 2: Orange-White/Orange; Pair 3: Green-White/Green; Pair 4: Brown-White/Brown
Separator: Cross-web
Flooding Compound: Waterproof gel
Jacket: UV- and Abrasion-Resistant Polyethylenes
Tech Info
Standard Compliances
ANSI/TIA 568-C.2
ISO 11801 (Category 6)
ICEA S-102-700 (Category 6)
Telcordia (Bellcore) Specification GR-421-CORE Water Penetration Requirement
RoHS Compliant Directive 2002/95/EC
Technical
Category
CATEGORY 6
Conductor Size
23 AWG (AMERICAN WIRE GAUGE)
Conductor Type
SOLID
Conductor/Pair Count
4 PAIR
Fire Rating
RISER
Jacket Color
BLACK
Shielded
U/UTP - UNSHIELDED TWISTED PAIR
Type
DATA
UNSPSC Code
26121609
