Model:
F1114-08 X 32D, CS414838SKU:
F1114-08 X 32D, CS414838Availability:
In Stockdocuments:
Spec Sheet
Request Quote
Features
- Accommodates 1/2 Inch, 5/8 Inch or 3/4 Inch Latch Projection
- Horizontal Adjustment Relieves Side-Load Pressure, Ensuring Proper Latch Alignment
- Saddle-Mount Housing Design for Enhanced Strength and Durability
- Unique Anti-Vibration Design Prevents Maniulation by Vibration
- Tamper-Resistant Pry-Guard Concealed Behind the Door Frame Increases Strength and Prevents Manipulation by Tool Attack
- Crossed Wires are Not a Problem, as Coil is Not Polarity Sensitive
- Energy Efficient Coil Design
- Internally Moued Solenoid for Easier Installation
- Non-Handed for Right or Left-Hand Doors
Technical
ANSI Grade
GRADE 1
Finish
US32D SATIN STAINLESS STEEL
Frame Material
HOLLOW METAL
Locking State
FAIL-SECURE (POWER TO UNLOCK)
Max Latch Length - Inch
MAXIMUM 3/4 INCH THROW
Mounting
FOR CENTERLINE INSTALLATIONS
Product Type
CYLINDRICAL OR MORTISE LOCKS
Pull Strength - Lbs
1000 - 1500 LBS.
Sales Category
ELECTRIC STRIKE
UL
UL 3-HOUR FIRE AND BURGLARY RESISTANCE
Voltage and Duty CONT
24 VOLT DC CONTINUOUS DUTY
Voltage and Duty INT
24 VOLT AC INTERMITTENT DUTY
Warranty
5 YEAR LIMITED
