Spec Sheet
Request Quote
Features
- No Cutting or Altering of the Jamb Required
- Releases Under Preload
- Fits Standard ANSI 4-7/8 Inch Strike Cutout
- Motorized, No Solenoids
- Fully Concealed Installation
- Maintains Deadlatch Function at All Times
- Continuous Duty
- Latch Status Sensor is Std
- One Model Works with Most North American Mortise Locks
- Mortise Unlatch is for any Application Where an Electric Strike Would be Used for a Mortise Type Lock
- The Mortise Unlatch Includes Field Adjustability for Latch and Deadlatch Positions, ReleasesUnder Pressure and Includes a Latch Status Monitoring Output
Technical
Frame Material
WOOD OR HOLLOW METAL
Max Latch Length - Inch
MAXIMUM 3/4 INCH THROW
Mounting
UNIVERSAL
Product Type
CYLINDRICAL OR MORTISE LOCKS
Pull Strength - Lbs
1000 - 1500 LBS.
Sales Category
ELECTRIC STRIKE
Switches
LATCHBOLT MONITOR
UL
UL 3-HOUR FIRE LABEL
Voltage and Duty INT
12 VOLT DC INTERMITTENT DUTY
Warranty
LIFETIME
