Features
- 50 Watt with 50 Watt as backup - 100 watt single channel - 100 watt single channel with 50 Watt backup using EVS-100WBU amplifier configurations
- Built in backup amplifier test feature allows you to physically test that the backup amplifier is operating properly
- Up to four amplifiers per 5820XL-EVS distributed between up to 32 audio circuits
- Six-wire connection to EVS system: Two-wires for the voice bus And four-wires for the SBUS connections
- Amplifier bandwidth 400 - 4000 Hz
- Can be mounted up to 60 ft. away from 5820XL-EVS control panel
- 10 mA Main EVS panel SBUS standby and alarm
- 18 AH max allowed in cabinet. Use RBB accessory cabinet for larger batteries up to 35 AH per system
- Voice Integration Wiring, six conductor, two voice bus, four SBUSÔircuit 1-4: 50 Watt max, Circuit 5-8: 50 Watt max
- Flush Mount Dimension: 24.75 Inch H x 14.5 Inch W x 3.4 Inch D
Tech Info
UL 2572, UL 1711, UL 864 And UL 2572, NFPA 13, NFPA 70, NFPA 72
Technical
UNSPSC Code
46171600
