TE-ENERGY 1-480702-0 Housing Plug, Wire-To-Board, Wire-To-Wire, 4 Connector

Specification Description

Industry Standards.RoHS/ELV Compliance: RoHS compliant, ELV compliant
Industry Standards.Lead Free Solder Processes: Not relevant for lead free process
Product Type Features.Color: Natural
Body Features.Number of Positions: 4
Packaging Features.Packang Method: One Piece Housing
Housing Features.UL Flammability Rating: UL 94V-2
Mechanical Attachment.Mating Retention Type: Positive Lock
Body Features.Centerline (mm [in]): 6.35 [0.250]
Housing Features.Connector Style: Plug
Body Features.Mating Retion: With
Product Type Features.Product Type: Connector
Contact Features.Contact Type: Pin or Socket
Product Type Features.Connector Type: Housing
Product Type Features.Product Line: Universal MATE-N-LOK
Housing Features.Housing Material: Nylon
Prt Type Features.Mount: Free Hanging
Electrical Characteristics.Current Rating (A): 19
Body Features.Contact Diameter (mm [in]): 2.13 [0.084]
Electrical Characteristics.Voltage (V AC): 600
Contact Features.Sealable: Yes
Electrical Characteristics.Higurrent: No
Contact Features.Contact Layout: In-Line
