Specification Description
Industry Standards.RoHS/ELV Compliance: RoHS compliant, ELV compliant
Industry Standards.Lead Free Solder Processes: Not relevant for lead free process
Body Features.Number of Positions: 7
Housing Features.UL Flammability Rating: UL 94V-0
Mechanical Attachment.Mating Retention Type: Threaded Coupling
Product Type Features.Sealed: No
Housing Features.Housing Color: Black
Housing Features.Mating Alignment Type: Keyed
Housing Features.Connector Style: Receptacle
Conditions for Usage.Accepts Wire Insulation Diameter, Range (mm [in]): 2.54 [0.100]
Contact Features.Contact Type: Socket
Product Type Features.Connector Type: Housing
Product Type Features.Shell Size: 13
Body Features.Mount Style: Flange with Mounting Holes
Product Type Features.Thread Size: 3/4 - 20 UNEF-2A
Housing Features.Housing Material: Nylon
Product Type Features.Mount: Panel
Environmental.Fluid Resistance: None
Product Type Features.Product Series: Series 1
Body Features.Number of Signal Positions: 7
Product Type Features.Shell Type: All Plastic
Product Type Features.Mount Angle: Straight
Configuration Features.Reverse Numbering: Without
Mechanical Attachment.Keying: A
Configuration Features.Environmental Protection: Without
Contact Features.Reverse Gender: Reverse
Industry Standards.VDE Tested: Yes
Product Type Features.PCB Mount Retention: Without
