Spec SheetSpecification Description
Industry Standards.RoHS/ELV Compliance: RoHS compliant, ELV compliant
Industry Standards.Lead Free Solder Processes: Not relevant for lead free process
Body Features.Number of Positions: 9
Packaging Features.Packaging Method: Bulk
Housing Features.UL Flammability Rating: UL 94V-0
Housing Features.Housing Color: Black
Housing Features.Connector Style: Plug
Product Type Features.Product Type: Connector
Contact Features.Contact Type: Pin
Product Type Features.Shell Size: 1
Packaging Features.Packaging Quantity: 100
Body Features.Cable Exit Angle: 180
Contact Features.Preloaded: Yes
Product Type Features.Body Material: Polypropylene
Electrical Characteristics.Shielded: Yes
Product Type Features.Grade: Standard
Product Type Features.Grommets: With
Product Type Features.Cable Clamp Type: One-Piece Quick Snap
Body Features.Cable Insulation Diameter (mm [in]): 4.70 8.13 [0.185 0.320]
Housing Features.Housing Material: Nylon, Polyester GF
Product Type Features.Product Series: HDP-20 (Crimp Snap)
Product Type Features.Shell Type: Full Metal Shell
Termination Features.Solder Tail Contact Plating: Tin over Nickel
Contact Features.Contact Base Material: Brass
Product Type Features.Mating Connector Lock Type: Mounting Holes
Product Type Features.Mating Connector Lock: With
Contact Features.Contact Plating, Mating Area, Material: Gold Flash
Product Type Features.Cable Support Gate Material: Polypropylene
Product Type Features.Screw Material: Steel
Mechanical Attachment.Mounting Screw Material: Steel
Mechanical Attachment.Screw Plating: Zinc
Product Type Features.Retainer Clip Material: Stainless Steel
Product Type Features.Screws and Retainer Clips: With
Product Type Features.Strain Relief Clip Material: Stainless Steel
Body Features.Wire Range (mm [AWG]): 0.2 - 0.56 [24-20]
Mechanical Attachment.Mounting Screw Plating: Zinc
