Features
- Adjustable dispersion angle to 60, 45, 30 or 15 degrees
- Improved intelligibility through tailored coverage
- Compact design includes four preassembled modules with four LF drivers and twelve HF dome tweeters
- In-line driver arrangement for superior vertial coverage control
- Horizontal coverage remains broad through speech range: 100 deg. fixed
- Contoured waveguide-baffle for distortion-free coverage control
- High power handling: 600 W cont. (200 W, 24 hr. pink noise)
- High sensitivity: up to 99 dB, 1 wa @ 1 meter (500 to 5,000 Hz)
- Stack up to four units for improved coverage control
- Lightweight polypropylene construction
- Available in black and white
- Weather-resistant versions
- Parallel connectors - dual Speakon and screw terminal
- Vertical or horizl mounting
- Built-in surface-mount bracket
- You can change the HX-5 coverage angle in seconds!
- Hardware included for flying / suspension
- Optional wall, ceiling and stand-mount hardware
- Optional bracket for joining multiples into one array
- Compatible Omnimount 60 Series mounting hardware
- Optional 70 volt transformer, model MT-200
- Five year warranty
Technical
UNSPSC Code
52161600
