Features
- Accepts a Bolt with a up to 5/8 inch Throw
- Non-Handed Unit (Except 458, 478 LO/RO)
- Fail Secure Standard Action (Unlock with Power)
- Mechanism Spacer Increase Cavity Depth up to 1/8 Inch
Technical
ANSI Grade
GRADE 1
Frame Material
HOLLOW METAL
Locking State
FAIL-SECURE (POWER TO UNLOCK)
Max Latch Length - Inch
MAXIMUM 5/8 INCH THROW
Mounting
FOR CENTERLINE INSTALLATIONS
Product Type
COMPONENT
Pull Strength - Lbs
1000 - 1500 LBS.
Sales Category
ELECTRIC STRIKE COMPONENT
Voltage and Duty CONT
SELECTABLE 12/24V DC
Voltage and Duty INT
SELECTABLE 12/24V AC/DC INT
