Spec Sheet
Applications
For Used Worldwide In High Fluctuating Networks And Battery-Powered Plants
Features
- Rated output current 2.5 A
- Efficiency of typical 86%
- Low power dissipation and low heating
- Free convection cooling (no forced cooling with ventilators)
- Ambient temperature range during operation Minus 40 - 70 deg C
- Open-circuit, overload and short-circuit stable
- Integrated input fuse U/I characteristic (fold-forward behaviour at overload - no switch-off)
- LEDs for status indication
- Structural form ideal for installation in distribution panels
- Light-grey enclosure in RAL 7035
- The primary switch mode power supply offers two voltage input ranges. This enables the supply with AC or DC
- Equipped with two generous capacitors, which ensure mains buffering of at least 60 usec
Specification Description
Voltage Rating: Input: 90 - 264 V AC/120 - 375 V DC, Output: 24 V DC
Amperage Rating: Input: 1120 mA At 115 V AC, 660 mA At 230 V AC, Output: 2.5 A At Less Than Or Equal To 55 deg C
Wattage: 60 W
Frequency Rating: 47 - 63 Hz
Phase: 1 PH
Fuse Rating:A At 250 V AC Slow Acting
Material: Plastic Housing
Efficiency: 86 %
Insulation: Rated Insulation Voltage Ui: Input/Output - 4 kV AC
Cable Size: Fine Strand With Wire End Ferrule: 24 - 14 AWG (Input/Output), Rigid: 24 - 12 AWG (Input/Output)
Enclosu IP20
Environmental Conditions: Operating Temperature: -40 To 70 deg C, Rated Load: -40 To 55 deg C, Storage Temperature: -40 To 85 deg C, Damp Heat, Cyclic: (4) 24 HR Cycles, 40 deg C, 95 % RH
Width: 71 mm
Height: 91 mm
Control Time: Less Than 1 mseCurrent Limiting At Short Circuit: 65 A
Power Failure Buffering Time: 60 msec
Rise Time: 1 msec
Wire Strip Length: 7 mm
Power Consumption: 69.3 W At 110 V AC, 70.1 W At 230 V AC
Inrush Current Limiting: 60 A
Depth: 57.5 mm
Tightening Torque: 0.7 N
Tech Info
C/US UL 508, 1310, 60950 Listed, CAN/CSA C22.2, CE, GOST Certified, IEC/EN 61204, EN 50178, EN 60950, IEC/CISPR 22, EN 55022: Class B Approved, RoHS Compliant
