Spec Sheet
$2,972.63
Estimated price. Final price and availability are subject to confirmation. Contact our sales team for a current quote.
Product Overview
10W Chemical Resistant Strobe LED Light - C1D2/C1D2 - Corrosion Resistant - Motion Sensor is a product intended for professional commercial and industrial applications.
Key Specifications
- Unit Type: Explosion Proof Light
- Lamp Dimensions (Ceiling Mount): 10.84"H x 4.75"OD
- Lamp Dimensions (Wall Mount): 7.3"L x 5.19"W x 12.26"H
- Motion Detector Dimensions: 7"-W x 5"-H x 9"-D
- Detection: Motion
- Detection Coverage: 15` x 15` (when mounted at 16`)
- Tilt Angles: -90° to +30° in elevation
- Voltage: 120V, 220-240V, 12V DC or 24V DC
- Output Hold Time: 0.5 seconds to 15 minutes (Adjustable)
- Mains Frequency: 50/60 Hz
This item is grouped with LED Lights.
Before ordering: Verify ratings, dimensions, compatibility, and installation requirements before ordering.
Specifications
Ambient Operating Temp Range
-50° C to +85°C
Amp draw
0.083A @ 120V, 0.042A @ 240V, 0.42A @ 24V
Beam Angle
Omni-Directional
Detection
Motion
Detection Coverage
15` x 15` (when mounted at 16`)
Housing Material
Polycarbonate
Lamp Dimensions (Ceiling Mount)
10.84"H x 4.75"OD
Lamp Dimensions (Wall Mount)
7.3"L x 5.19"W x 12.26"H
Lamp Watts
10W
Lighting Configuration
Strobe
Luminous Efficacy
105 Lm/W
Mains Frequency
50/60 Hz
Motion Detector Dimensions
7"-W x 5"-H x 9"-D
Mounting
Ceiling or Wall
Operating Temp Rating
T2D
Output Hold Time
0.5 seconds to 15 minutes (Adjustable)
Power Efficiency
>95%
Radiated Frequency
5.8 GHz
Tilt Angles
-90° to +30° in elevation
Unit Type
Explosion Proof Light
Voltage
120V, 220-240V, 12V DC or 24V DC
Weight
9 lbs
Wiring Hub
3/4" NPT
Technical
Color Rendering Index
>80 CRI
Color Temp
6000K, 4500K, 3000K, Red, Blue, Amber or Green
Lamp Life
50,000+ Hours
Lumens
1,050
Lamp Type
A19 LED
Power Factor
0.992
Lens Material
Hardened Borosilicate Glass
