Model:
VFD-3P-460-15HP-25A-DCMSKU:
VFD-3P-460-15HP-25A-DCMAvailability:
In StockDocuments:
Spec Sheet
$3,431.05
Estimated price. Final price and availability are subject to confirmation. Contact our sales team for a current quote.
Product Overview
15HP Variable Frequency Device - 460V AC 3PH Input/Output - 25 Amps - 11kW is a product intended for professional commercial and industrial applications.
Key Specifications
- Unit Type: 3 Phase Delta, 3 Wire Variable Frequency Device
- Dimensions: 13.34" x 9.09" x 8.42"
- Weight: 24.25 lbs
- Input/Output Voltage: 460V (415-500V) AC 3PH
- Output Current: 25 Amps
- Operating Frequency: 0 to 3000 Hz
- Kilowatts: 11kw
- HP: 15
- Starting Torque: 1 Hz/150%
- Carrier Frequency: 1.0-16kHz, auto adjusted according to temperature and load
This item is grouped with 440V 460V 480V Variable Frequency Drives (VFDs).
Before ordering: Verify ratings, dimensions, compatibility, and installation requirements before ordering.
Specifications
Analog Input/Output
2 Input (0~10V or 0/4~20mA), 2 Output (0/4~20mA or 0~10V)
Carrier Frequency
1.0-16kHz, auto adjusted according to temperature and load
Color
Gray
Communication Terminal
RS485 communication interface, support MODBUS-RTU communication protocol
Dimensions
13.34" x 9.09" x 8.42"
Frequency Accuracy
Digital setting: 0.01Hz, Analog Setting: Max frequency X 0.05%
HP
15
Input/Output Voltage
460V (415-500V) AC 3PH
Inputs
7 on-off programmable digital, 1 high-speed pulse, 2 programmable analog (AI1: 0~10V or 0/4~20mA A12: 0~10V or 0/4~20mA)
Kilowatts
11kw
Materials
-
Max Operating Humidity
90% (non condensing)
Mounting
Surface
Operating Frequency
0 to 3000 Hz
Operating Temp
–10°C to +40°C
Output Current
25 Amps
Outputs
1 programmable open collector, 1 analog (open collector or high-speed pulse), 2 relay, 2 analog (0/4~20mA or 0~10V)
Overload
150% @ 60s, 180% @ 10s, 200% @ 3s
Starting Torque
1 Hz/150%
Torque Boost
Automatic torque boost; manual torque boost: 0.1%~30.0%
Unit Type
3 Phase Delta, 3 Wire Variable Frequency Device
V/f curve
Linear, multiple point and square type (1.2 power, 1.4 power, 1.6 power, 1.8 power, square)
Weight
24.25 lbs
