700 kVA Transformer - 13200V Delta Primary Voltage - 480Y/277 Wye-N Voltage Secondary - NEMA 3R

Product Overview

700 kVA Transformer - 13200V Delta Primary Voltage - 480Y/277 Wye-N Voltage Secondary - NEMA 3R is a product intended for professional commercial and industrial applications.

Key Specifications

• Transformer Features: With a transformer rating of 700 kVA, the MT-PMD-3P-13200D-700KVA-480Y.277-N3R transformer is a three phase unit with a primary voltage of 13200 V Delta. It also provides a secondary voltage of 480Y/277 V Wye-N. Featuring robust construction, this unit`s cores are manufactured with non-aging, cold-rolled silicon steel laminations using state of the art technology.
• Benefits: The MT-PMD-3P-13200D-700KVA-480Y.277-N3R general purpose transformer offers many benefits to the consumer. Precision cut aluminum transformer winding material help to improve performance. The close tolerances used during manufacturing also eliminates burrs which hinder performance. Each core is specially coated to prevent the ingress of moisture and are electrically balanced to minimize axial forces during short circuit situations.
• Applications: General purposes.

This item is grouped with Medium Voltage Pad Mount Transformers.

Before ordering: Verify ratings, dimensions, compatibility, and installation requirements before ordering.
