Model:
DCP-208-15.5V-250.350ASKU:
DCP-208-15.5V-250.350AAvailability:
In StockDocuments:
Spec Sheet
$52,389.84
Estimated price. Final price and availability are subject to confirmation. Contact our sales team for a current quote.
Product Overview
AC/DC Converter - 208V Input, 15.5V DC Adjustable Output - 250-350 Amp Max is a product intended for professional commercial and industrial applications.
Key Specifications
- Line In Voltage: 208VAC @47-63 hz
- Line Out: 15.5VDC adjustable @250-350 Amp
- Watts: 4000 to 5000
- AC Input Connector: 1` Pigtail, Straight Blade Plug
- DC Output Connector: 1` Pigtail, Cigarette Plug Socket
- Protection: Above 105% Rated Output Power, Hiccup Mode - Recovers automatically after fault condition is removed
- Mounting: Two Screw Slide Notches
- Operating Temp: -5/ +55C
- Operating Humidity: -20 to 90% Rh Non Condensing
- Vibration: -10 to500Hz, 2GT, 20min/sweep, Perios - 1 hr, each along x,y,z axes
This item is grouped with 12 / 24 Volt Lights.
Before ordering: Verify ratings, dimensions, compatibility, and installation requirements before ordering.
Specifications
AC Input Connector
1` Pigtail, Straight Blade Plug
Cooling
Forced cooling
DC Output Connector
1` Pigtail, Cigarette Plug Socket
Dimensions
19.01"-L x20.98"-D x5.71"-H
Efficiency
85%
Enclosure
IP-21
Line In Voltage
208VAC @47-63 hz
Line Out
15.5VDC adjustable @250-350 Amp
Mounting
Two Screw Slide Notches
Operating Humidity
-20 to 90% Rh Non Condensing
Operating Temp
-5/ +55C
Protection
Above 105% Rated Output Power, Hiccup Mode - Recovers automatically after fault condition is removed
Vibration
-10 to500Hz, 2GT, 20min/sweep, Perios - 1 hr, each along x,y,z axes
Watts
4000 to 5000
Weight
51 Lbs
