ANDREW ATM200-A20 Actuator, AISG 2.0 Default Protocol

Features

• OMT platform reduces cable diameter while optimizing transmission performance
• Can support network line speeds up to 10 gigabits per second
• Qualifies for the SYSTIMAX 20-Year Extended Product Warranty and Applications Assurance when included as part of a registered SYSTIMAX GigaSPEED X10D channel

Specification Description

Actuator
AISG Input Connector Quantity: 1
AISG Output Connector Quantity: 1
Lightning Surge Capability Waveform: 1.2/50 Voltage and 8/20 Current Combination Waveform
Input Voltage: 10 - 30 Volt DC
Adjustment Cycles (Minimum): 10000 Cycles
Height: 203.20 mm (8.00 Inch)
Adjustment Time (Full Range, Maximum): 22 Sec
Operating Temperature: -40 to 70 deg C (-40 to 158 deg F)
Lightning Surge Capability: 5 Times At -3 kA
Depth: 53.3 mm (2.1 Inch)
Width: 71.1 mm (2.8 Inch)
AISG Output Connector: 8-Pin DIN Female
AISG Input Connector: 8-Pin DIN Male
Material Type: ABS
Protocol: AISG 1.1, AISG 2.0
Default Protocol: AISG 2.0
Color: Black
Interface Protocol Signal: Data, DC
Relative Humidity: Upto 100%

Tech Info

ISO 9001:2008: Designed, manufactured and/or distributed under this quality management system; AISG: Compliant
