Model:
HAL-MTPC-VHD-RB-208V-60HP-25HP-N3RSKU:
HAL-MTPC-VHD-RB-208V-60HP-25HP-N3RAvailability:
In StockDocuments:
Spec Sheet
$21,719.44
Estimated price. Final price and availability are subject to confirmation. Contact our sales team for a current quote.
Product Overview
C1D2 Hazloc Rotary Phase Converter,25HP Very Hard Load, 208V 1PH to 3PH, 75.6A Output, 60HP Idler is a product intended for professional commercial and industrial applications.
Key Specifications
- Unit Type: Rotary Phase Converter
- Phase Conversion: Single Phase to Three Phase
- Kilowatt Rating: 44.7 KW
- Kilo Volt-Amp Rating: 60 KVA
- Idle Motor Horse Power: 60 HP
- Single Phase Voltage Input: 208V
- Minimum Fuse/Circuit Breaker Size: 100
- Maximum Fuse/Circuit Breaker Size: 300
- Minimum Wire (Input) to Converter: 3/0 AWT
- Minimum Electrical Service Required: 75 KVA
This item is grouped with Single Phase to Three Phase Converters for Very Hard Motor Loads.
Before ordering: Verify ratings, dimensions, compatibility, and installation requirements before ordering.
Specifications
Color
Natural Gray
Dimensions
-
Idle Amps
-
Idle Motor Horse Power
60 HP
Kilo Volt-Amp Rating
60 KVA
Kilowatt Rating
44.7 KW
Maximum Fuse/Circuit Breaker Size
300
Maximum Output Amps
159A
Maximum Resistive Amps
84A
Maximum Single Motor Load HP
25 HP
Minimum Electrical Service Required
75 KVA
Minimum Fuse/Circuit Breaker Size
100
Minimum Wire (Input) to Converter
3/0 AWT
Minimum Wire to Device Load
2 AWG
Optimal Output Amps
75.6A
Phase Conversion
Single Phase to Three Phase
Recommended Combined HP
25 HP
Service Load Type
Very Hard motor loads
Shipping Dimensions
-
Shipping Weight
- lbs
Single Phase Voltage Input
208V
Three Phase Voltage Output
208
Unit Type
Rotary Phase Converter
Voltage Balance
2-5%
Weight
- lbs
Technical
Form Factor
Rectangular Enclosure, Cylindrical Idler w/ Four Legs
