Spec Sheet
$2,384.88
Estimated price. Final price and availability are subject to confirmation. Contact our sales team for a current quote.
Product Overview
Ceiling Mount Explosion Proof 150 Watt High Bay LED Light Fixture - Paint Spray Booth Approved is a product intended for professional commercial and industrial applications.
Key Specifications
- Listing: United States - Canada
- Lamp Type: Cree
- Dimensions: 14"H x 16"W x 11"D
- Weight: 35 lbs
- Voltage: 100-277 Volts AC, 50/60Hz or 11-25 Volts AC/DC
- Total Watts: 150W
- Total Lumens: 21,000
- Luminous Efficiency: 140 Lm/W
- Lamp Life: 60,000+ Hours
- Color Temp: 5600K, 5000K, 4500K, 4000K, 3500K, 3000K, 2700K, or 6500K
This item is grouped with Explosion Proof Lighting.
Before ordering: Verify ratings, dimensions, compatibility, and installation requirements before ordering.
Specifications
Ambient Operating Temp Range
-50° C to +65°C
Beam Angle
60°, 125°, or 140°
BUG Rating
B5-U1-G1 (60° Optics); B4-U1-G1 (125° Optics); B4-U1-G2 (140° Optics)
CIE Type
Direct
Cutoff Classification
Cutoff
Dimensions
14"H x 16"W x 11"D
Gasket Material
Silicone
Housing Material
Copper Free Cast Aluminum
IES Classification
Type I (60° Optics); Type VS (125° Optics); Type VS (140° Optics)
Lighting Configuration
Flood Pattern
Listing
United States - Canada
Longitudinal Classification
Very Short (60° Optics); Very Short (125° Optics); Short (140° Optics)
Luminous Efficiency
140 Lm/W
Mounting
Ceiling Mount Junction Box
NEMA Type (Lighting)
6H x 6V (60° Optics); 6H x 6V (125° Optics); 6H x 7V (140° Optics)
Operating Temp Rating
T5
Power Efficiency
>95%
Total Lumens
21,000
Total Watts
150W
Voltage
100-277 Volts AC, 50/60Hz or 11-25 Volts AC/DC
Weight
35 lbs
Wiring Hub
3/4" NPT
Technical
Color Rendering Index
>75 CRI
Color Temp
5600K, 5000K, 4500K, 4000K, 3500K, 3000K, 2700K, or 6500K
Lamp Life
60,000+ Hours
Wiring
(3) 3/4" NPT Hubs on Ceiling Mount
Lamp Type
Cree
Power Factor
0.992
Lens Material
Hardened Borosilicate Glass
