Model:
BENXT-430-XSKU:
SAFSALE-1205921Availability:
In Stock
$6,105.94
Estimated price. Final price and availability are subject to confirmation. Contact our sales team for a current quote.
The Ensemble Designs BrightEye NXT 430-X Compact Router BENXT-430-X is a versatile device designed for various signal transmission needs. It supports multiple signal types including SD SDI, SMPTE 259M at 270 Mb/s, HD SDI, SMPTE 274M, 292M, 296M at 1.485 Gb/s, and HD SDI, SMPTE 424M, 425M at 2.97 Gb/s. The router has a 75 Ohm impedance and a return loss of over 15 dB. It also features a 1 V p-p composite video input that supports PAL or NTSC, with a return loss of over 40 dB. The maximum cable length varies depending on the signal type, with 984.3' (300.0 m) for SD and 328.1' (100.0 m) for HD. The device includes two inputs and two outputs via SFP.
- Number: 2 to 5, configurable, BNC, and SFP
- Signal Type: 270 Mb/s: SD SDI, SMPTE 259M 1.485 Gb/s: HD SDI,SMPTE 274M, 292M, 296M 2.97 Gb/s: HD SDI, SMPTE 424M, 425M
- Impedance: 75 Ohms
- Return Loss: >15 dB
- Maximum Cable Length: 984.3' (300.0 m) for 270 Mb/s 328.1' (100.0 m) for 1.485 Gb/s
Specifications
Altitude
0 to 10,000' (0 to 3,048 m)
Box Dimensions (LxWxH)
9.9 x 9.8 x 3.3"
Package Weight
3.285 lb
Processing
12 and 16-bit
Relative Humidity
0 to 95% (non-condensing)
Signal Type
270 Mb/s: SD SDI, SMPTE 259M 1.485 Gb/s: HD SDI,SMPTE 274M, 292M, 296M 2.97 Gb/s: HD SDI, SMPTE 424M, 425M
Return Loss
>15 dB
Supported Standards
1080i: 50, 59.94, or 60 Hz, SMPTE 274M: -4, 5, 6 720p: 50, 59.94, or 60 Hz, SMPTE 296M: -1, 2, 3 1080p: 23.98, 24, or 25 Hz, SMPTE 274M: -9, 10, 11 1080p: 50, 59.94, 60 Hz, SMPTE 424M, 425M, level A 1080sF: 23.98, 24, or 25 Hz, RP211: -14, 15, 16 625i: 50 Hz 525i: 59.94 Hz
Maximum Cable Length
984.3' (300.0 m) for 270 Mb/s 328.1' (100.0 m) for 1.485 Gb/s
Number
2 to 5, configurable, BNC, and SFP
Technical
Dimensions
5.63 x 1.65 x 6.75" (14.30 x 4.19 x 17.14 cm)
Impedance
75 Ohms
Power
12 V, 20 W (100 to 230 VAC modular power supply)
Type
1 V p-p composite video, PAL or NTSC or tri-level sync
Weight
1.75 lb (794 g) including connectors and flange
Temperature Range
32 to 104°F (0 to 40° C) ambient
